SB Acoustics SB17CAC35-8 6'' Ceramic Cone Woofer

SB Acoustics

SB Acoustics SB17CAC35-8 6'' Ceramic Cone Woofer


Product Specifications
Nominal Impedance 8 ohms
DC resistence,Re 5.7 ohms
voice coil inductance,Le 0.15 mH
Free air resonance,Fs 28 Hz
Sensitivity(2.83V/1m) 86.5 dB
Mechanical Q-factor,Qms 4.46
Electrical Q-factor,Qes 0.40
Total Q-factor,Qts 0.36
Moving mass incl. air,Mms 15.4 g
Force factor,BI 6.2 Tm
Equivalent volume,Vas 42 liters
Compliance,Cms 2.13 mm/N
Mechanical loss,Rms 0.6 Kg/s
Rated power handling* 60W
Effective piston area,Sd 118 cm²
Voice coil diameter 35.5 mm
Voice coil height 16 mm
Air gap height 5 mm
Linear coil travel(p-p) 11 mm
Magnetic flux density 1.0 T
Magnetic weight 0.4 Kg
Net weight 1.56 Kg

Frequency and Impedance Graph:

SB Acoustics SB17CAC35-8 6'' Ceramic Cone Woofer

Drawing:

SB Acoustics SB17CAC35-8 6'' Ceramic Cone Woofer
